K8S的RBAC和API-Server认证机制

API Server内置的访问控制机制

1.API Server的访问方式

API Server的访问方式:
	- 集群外部: https://IP:Port
		比如: https://10.0.0.231:6443

	- 集群内部: https://kubernetes.default.svc
		比如:  直接基于名为"kubernetes"的svc访问即可

[root@master231 ~]# kubectl get svc kubernetes
NAME         TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)   AGE
kubernetes   ClusterIP   10.200.0.1   <none>        443/TCP   6d22h
[root@master231 ~]#
[root@master231 ~]# kubectl describe svc kubernetes  | grep Endpoints
Endpoints:         10.0.0.231:6443
[root@master231 ~]#

API Server内置了插件化的访问控制机制(每种访问控制机制均有一组专用的插件栈)
	认证(Authentication)：
		核验请求者身份的合法性，进行身份识别，验证客户端身份。
		身份核验过程遵循“或”逻辑，且任何一个插件核验成功后都将不再进行后续的插件验证。
		均不成功，则失败，或以“匿名者”身份访问，建议禁用“匿名者”。

	授权(Authorization)：
		核验请求的操作是否获得许可，验证客户端是否有权限操作资源对象。
		鉴权过程遵循“或”逻辑，且任何一个插件对操作的许可授权后都将不再进行后续的插件验证。
		均未许可，则拒绝请求的操作

	准入控制(Admission Control)：
		检查操作内容是否合规，仅同"写"请求相关，负责实现"检验"字段类型是否合法及和补全默认字段。
		内容合规性检查过程遵循“与”逻辑，且无论成败，每次的操作请求都要经由所有插件的检验。
		将数据写入etcd前，负责检查内容的有效性，因此仅对“写”操作有效。
		分两类：validating（校验）和 mutating（补全或订正）。

2.身份认证策略

- X.509客户端证书认证:
	在双向TLS通信中，客户端持有数字证书信任的CA，需要在kube-apiserver程序启动时，通过--client-ca-file选项传递。
	认证通过后，客户端数字证书中的CN（Common Name）即被识别为用户名，而O（Organization）被识别为组名。
	kubeadm部署的K8s集群，默认使用"/etc/kubernetes/pki/ca.crt"(各组件间颁发数字证书的CA)进行客户端认证。


- 持有者令牌:
	- 1.静态令牌文件（Static Token File）:
		令牌信息保存于文本文件中，由kube-apiserver在启动时通过--token-auth-file选项加载。
		加载完成后的文件变动，仅能通过重启程序进行重载，因此，相关的令牌会长期有效。
		客户端在HTTP请求中，通过“Authorization: Bearer TOKEN”标头附带令牌令牌以完成认证。

	- 2.Bootstrap令牌:
		一般用于加入集群时使用，尤其是在集群的扩容场景时会用到。

	- 3.Service Account令牌:
		该认证方式将由kube-apiserver程序内置直接启用，它借助于经过签名的Bearer Token来验证请求。
		签名时使用的密钥可以由--service-account-key-file选项指定，也可以默认使用API Server的tls私钥
		用于将Pod认证到API Server之上，以支持集群内的进程与API Server通信。
		K8s可使用ServiceAccount准入控制器自动为Pod关联ServiceAccount。

	- 4.OIDC（OpenID Connect）令牌:
		有点类似于"微信"，"支付宝"认证的逻辑，自建的话需要配置认证中心。
		OAuth2认证机制，通常由底层的IaaS服务所提供。

	- 5.Webhook令牌:
		基于web的形式进行认证，比如之前配置的"钉钉机器人"，"微信机器人"等;
		是一种用于验证Bearer Token的回调机制，能够扩展支持外部的认证服务，例如LDAP等。

- 身份认证代理（Authenticating Proxy）:
	由kube-apiserver从请求报文的特定HTTP标头中识别用户身份，相应的标头名称可由特定的选项配置指定。
	kube-apiserver应该基于专用的CA来验证代理服务器身份。

- 匿名请求:
	生产环境中建议禁用匿名认证。

3.Kubernetes上的用户

“用户”即服务请求者的身份指代，一般使用身份标识符进行识别，比如用户名，用户组，服务账号，匿名用户等。

Kubernetes系统的用户大体可分Service Account，User Account和Anonymous Account。
	Service Account:
		Kubernetes内置的资源类型，用于Pod内的进程访问API Server时使用的身份信息。
		引用格式: "system:serviceaccount:NAMESPACE:SA_NAME"

	User Account:
		用户账户，指非Pod类的客户端访问API Server时使用的身份标识，一般是现实中的“人”。
		API Server没有为这类账户提供保存其信息的资源类型，相关的信息通常保存于外部的文件或认证系统中。
		身份核验操作可由API Server进行，也可能是由外部身份认证服务完成。
		可以手动定义证书，其中O字段表示组，CN字段表示用户名。

	Anonymous Account:
		不能被识别为Service Account，也不能被识别为User Account的用户。
		这类账户K8S系统称之为"system:anonymous"，即“匿名用户”。

静态令牌文件认证测试案例

1.模拟生成token

1.1 方式1 ：
[root@master231 ~]# echo "$(openssl rand -hex 3).$(openssl rand -hex 8)"
01b202.d5c4210389cbff08
[root@master231 ~]#
[root@master231 ~]# echo "$(openssl rand -hex 3).$(openssl rand -hex 8)"
497804.9fc391f505052952
[root@master231 ~]#
[root@master231 ~]#
[root@master231 ~]# echo "$(openssl rand -hex 3).$(openssl rand -hex 8)"
8fd32c.0868709b9e5786a8
[root@master231 ~]#

		1.2 方式2 ：
[root@master231 ~]# kubeadm token generate
jvt496.ls43vufojf45q73i
[root@master231 ~]#
[root@master231 ~]# kubeadm token generate
qo7azt.y27gu4idn5cunudd
[root@master231 ~]#
[root@master231 ~]#
[root@master231 ~]# kubeadm token generate
mic1bd.mx3vohsg05bjk5rr
[root@master231 ~]#
[root@master231 pki]# kubeadm token list
TOKEN                     TTL         EXPIRES   USAGES                   DESCRIPTION                                                EXTRA GROUPS
oldboy.laxjason   <forever>   <never>   authentication,signing   <none>                                                     system:bootstrappers:kubeadm:default-node-token
[root@master231 pki]#

2.创建csv文件

[root@master231 ~]# cd /etc/kubernetes/pki/
[root@master231 pki]#
[root@master231 pki]# cat token.csv
01b202.d5c4210389cbff08,lax,10001,k8s
497804.9fc391f505052952,jasonyin,10002,k8s
8fd32c.0868709b9e5786a8,linux96,10003,k3s
jvt496.ls43vufojf45q73i,linux97,10004,k3s
qo7azt.y27gu4idn5cunudd,linux98,10005,k3s
mic1bd.mx3vohsg05bjk5rr,linux99,10006,k3s
[root@master231 pki]#


温馨提示:
	文件格式为CSV，每行定义一个用户，由“令牌、用户名、用户ID和所属的用户组”四个字段组成，用户组为可选字段
	具体格式: token,user,uid,"group1,group2,group3"

3.修改api-server参数加载token文件

[root@master231 pki]# vim /etc/kubernetes/manifests/kube-apiserver.yaml
...
spec:
  containers:
  - command:
    - kube-apiserver
    - --token-auth-file=/etc/kubernetes/pki/token.csv
    ...
    volumeMounts:
    ...
    - mountPath: /etc/kubernetes/pki/token.csv
      name: lax-static-token-file
      readOnly: true
  ...
  volumes:
  ...
  - hostPath:
      path: /etc/kubernetes/pki/token.csv
      type: File
    name: lax-static-token-file
...

[root@master231 pki]# kubectl get pods -n kube-system  # 最少要等待30s+
NAME                                READY   STATUS    RESTARTS        AGE
...
kube-apiserver-master231            1/1     Running   1 (15s ago)     52s
...
[root@master231 pki]#

4.kubectl使用token认证并指定api-server的证书

[root@worker232 ~]# kubectl --server=https://10.0.0.231:6443  --certificate-authority=/etc/kubernetes/pki/ca.crt --token=01b202.d5c4210389cbff08 get nodes
Error from server (Forbidden): nodes is forbidden: User "lax" cannot list resource "nodes" in API group "" at the cluster scope
[root@worker232 ~]#
[root@worker232 ~]# kubectl --server=https://10.0.0.231:6443  --certificate-authority=/etc/kubernetes/pki/ca.crt --token=8fd32c.0868709b9e5786a8 get nodes
Error from server (Forbidden): nodes is forbidden: User "linux96" cannot list resource "nodes" in API group "" at the cluster scope
[root@worker232 ~]#
[root@worker232 ~]# kubectl --server=https://10.0.0.231:6443  --certificate-authority=/etc/kubernetes/pki/ca.crt --token=oldboy.laxjason  get nodes
Error from server (Forbidden): nodes is forbidden: User "system:bootstrap:oldboy" cannot list resource "nodes" in API group "" at the cluster scope
[root@worker232 ~]#
[root@worker232 ~]# kubectl --server=https://10.0.0.231:6443  --certificate-authority=/etc/kubernetes/pki/ca.crt --token=newboy.laxjason  get nodes
error: You must be logged in to the server (Unauthorized)  # 未认证！
[root@worker232 ~]#
[root@worker232 ~]# kubectl --server=https://10.0.0.231:6443  --certificate-authority=/etc/kubernetes/pki/ca.crt  get nodes  # 不使用token登录，判定为匿名用户
Please enter Username: admin
Please enter Password: Error from server (Forbidden): nodes is forbidden: User "system:anonymous" cannot list resource "nodes" in API group "" at the cluster scope
[root@worker232 ~]#

5.curl基于token认证案例

[root@worker232 ~]# curl -k https://10.0.0.231:6443   # 如果不指定认证信息，将被识别为匿名"system:anonymous"用户。
{
  "kind": "Status",
  "apiVersion": "v1",
  "metadata": {},
  "status": "Failure",
  "message": "forbidden: User \"system:anonymous\" cannot get path \"/\"",
  "reason": "Forbidden",
  "details": {},
  "code": 403
}[root@worker232 ~]#
[root@worker232 ~]# curl -k -H "Authorization: Bearer 01b202.d5c4210389cbff08"  https://10.0.0.231:6443/api/v1/pods
{
  "kind": "Status",
  "apiVersion": "v1",
  "metadata": {},
  "status": "Failure",
  "message": "pods is forbidden: User \"lax\" cannot list resource \"pods\" in API group \"\" at the cluster scope",
  "reason": "Forbidden",
  "details": {
    "kind": "pods"
  },
  "code": 403
}[root@worker232 ~]#
[root@worker232 ~]#
[root@worker232 ~]# curl -k -H "Authorization: Bearer 8fd32c.0868709b9e5786a8"  https://10.0.0.231:6443/api/v1/pods
{
  "kind": "Status",
  "apiVersion": "v1",
  "metadata": {},
  "status": "Failure",
  "message": "pods is forbidden: User \"linux96\" cannot list resource \"pods\" in API group \"\" at the cluster scope",
  "reason": "Forbidden",
  "details": {
    "kind": "pods"
  },
  "code": 403
}[root@worker232 ~]#
[root@worker232 ~]#  curl -k -H "Authorization: Bearer oldboy.laxjason"  https://10.0.0.231:6443/api/v1/pods
{
  "kind": "Status",
  "apiVersion": "v1",
  "metadata": {},
  "status": "Failure",
  "message": "pods is forbidden: User \"system:bootstrap:oldboy\" cannot list resource \"pods\" in API group \"\" at the cluster scope",
  "reason": "Forbidden",
  "details": {
    "kind": "pods"
  },
  "code": 403
}[root@worker232 ~]#
[root@worker232 ~]#
[root@worker232 ~]# curl -k -H "Authorization: Bearer newboy.laxjason"  https://10.0.0.231:6443/api/v1/pods
{
  "kind": "Status",
  "apiVersion": "v1",
  "metadata": {},
  "status": "Failure",
  "message": "Unauthorized",
  "reason": "Unauthorized",
  "code": 401  # 认证失败！
}[root@worker232 ~]#

X509数字证书认证测试案例

1.客户端节点创建证书签发请求

                1.1 创建证书签署请求的密钥
[root@worker233 ~]# openssl genrsa -out jiege.key 2048
[root@worker233 ~]#
[root@worker233 ~]# ll jiege.key
-rw------- 1 root root 1704 Apr 14 10:43 jiege.key
[root@worker233 ~]#



		1.2 创建证书签署请求
[root@worker233 ~]# openssl req -new -key jiege.key  -out jiege.csr -subj "/CN=jiege/O=violet"
[root@worker233 ~]#
[root@worker233 ~]# ll jiege*
-rw-r--r-- 1 root root  911 Apr 14 10:43 jiege.csr
-rw------- 1 root root 1704 Apr 14 10:43 jiege.key
[root@worker233 ~]#



		1.3 将证书签署请求证书使用base64编码
[root@worker233 ~]# cat jiege.csr  | base64 | tr -d '\n';echo
LS0tLS1CRUdJTiBDRVJUSUZJQ0FURSBSRVFVRVNULS0tLS0KTUlJQ2FUQ0NBVkVDQVFBd0pERU9NQXdHQTFVRUF3d0ZhbWxsWjJVeEVqQVFCZ05WQkFvTUNXOXNaR0p2ZVdWawpkVENDQVNJd0RRWUpLb1pJaHZjTkFRRUJCUUFEZ2dFUEFEQ0NBUW9DZ2dFQkFOT2l5Q0hwNkxJd0ZVZ0RoUldFCmtRaUo2Z1VsMnJGd3dQMEZSQW9PVHBnVUVLVmc4NlhBczdNN1hreWpvdzE2clF0djd3OW9DQXNHTEYwTll6ak0Kc3lzR1VzRnYrWEFlTDVhL0xhMzlKRHhnMHRZNFp2R3MvNDlYYkM0dnoxcmJpbWxVNmJGQ1M1RFduOWJSRWJlKwpyQk9oWERKT3czS0tRU09Bc3FiSXA1NVRWb3dxeDY3bk13SXlQVmVkWkRvMWpTbkJidlVZYXFlKzdiVzlNbVBVCmg0VGg4blRDZ2ZWeUwrK1VvWDJVT2lJQTdvQWdaNURRVTZXSXg2TFRUT0pSWG1HNDRBVm53ckhJeUZNWFBKNXcKa2pPRlRTd3FIdGk1L0hsUEZvdk45eHk4MTgrb3QzalNlQ1pIVjdiamlQNEd0UWlsNExZUmZURFJiTUJyc2EvUgpWajBDQXdFQUFhQUFNQTBHQ1NxR1NJYjNEUUVCQ3dVQUE0SUJBUUIvMHFIUXJ4RUZtMDF0YldpdDZUV2JMaitQClozQVN1M2FYcmN1aDlJR1Fwd2hselIyLzlqSTNuOEpOaTkxZm1xQUhhUjdsaXUzVEtWdnlTWHBocHVHNGxDNjgKQVpwenhIdndMZ1E5ZWJYSU5BYTRMTkxpTXdNVkpxOUphZjF2bzdqMTRzcHVWbjBFeFczSVZOeG9vODU4YXBxOQpBK2RFK3hwYTQwaEszUmRkR3A5YVdWOStOU1RMNm5zVmFqOUQwTVR2MG1kR0lqdGZmODJhTVZKb3ZTQStDMys0CkpmeGtOb0tSUE40RUZtTW1IbkhFMUZwTnhjWFpMODUvOWZYYVVESXdKVnRuQXYxWFNyMTZRcVNPUDNRWHM2QTUKdnIrZlZVeDdzVHFuYTZJRXQ5cjgrb1VOTVVybkNTOUpraG12Y2FBQUF4WkNVTDZxM2l3dTNNdis0clRtCi0tLS0tRU5EIENFUlRJRklDQVRFIFJFUVVFU1QtLS0tLQo=
[root@worker233 ~]#

2.服务端签发证书

           2.1 为客户端创建csr资源证书签发请求资源清单
[root@master231 ~]# cat csr-jiege.yaml
apiVersion: certificates.k8s.io/v1
kind: CertificateSigningRequest
metadata:
  name: jiege-csr
spec:
  # 将客户端证书签发请求使用base64编码存储，拷贝上一步生成的base64代码替换即可。
  request: 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
  # 指定颁发证书的请求类型，仅支持如下三种，切均可以由kube-controllmanager中的“csrsigning”控制器发出。
  #   "kubernetes.io/kube-apiserver-client":
  #      颁发用于向kube-apiserver进行身份验证的客户端证书。
  #      对该签名者的请求是Kubernetes控制器管理器从不自动批准。
  #
  #   "kubernetes.io/kube-apiserver-client-kubelet":
  #     颁发kubelets用于向kube-apiserver进行身份验证的客户端证书。
  #     对该签名者的请求可以由kube-controllermanager中的“csrapproving”控制器自动批准。
  #
  #   "kubernetes.io/kubelet-serving":
  #     颁发kubelets用于服务TLS端点的证书，kube-apiserver可以连接到这些端点安全。
  #     对该签名者的请求永远不会被kube-controllmanager自动批准。
  signerName: kubernetes.io/kube-apiserver-client
  # 指定证书的过期时间，此处我设置的是24h（3600*24=86400）
  expirationSeconds: 86400
  # 指定在颁发的证书中请求的一组密钥用法。
  #   对TLS客户端证书的请求通常请求：
  #       “数字签名(digital signature)”、“密钥加密(key encipherment)”、“客户端身份验证(client auth)”。
  #   对TLS服务证书的请求通常请求：
  #       “密钥加密(key encipherment)”、“数字签名(digital signature)”、“服务器身份验证(server auth)”。
  #
  # 有效值的值为: "signing", "digital signature", "content commitment", "key encipherment","key agreement",
  # "data encipherment", "cert sign", "crl sign", "encipher only", "decipher only", "any", "server auth",
  # "client auth", "code signing", "email protection", "s/mime", "ipsec end system", "ipsec tunnel","ipsec user",
  # "timestamping", "ocsp signing", "microsoft sgc", "netscape sgc"。
  usages:
  - client auth
[root@master231 ~]#


		2.2 创建证书签发请求
[root@master231 ~]# kubectl get csr
No resources found
[root@master231 ~]#
[root@master231 ~]# kubectl apply -f csr-jiege.yaml
certificatesigningrequest.certificates.k8s.io/jiege-csr created
[root@master231 ~]#
[root@master231 ~]# kubectl get csr
NAME        AGE   SIGNERNAME                            REQUESTOR          REQUESTEDDURATION   CONDITION
jiege-csr   1s    kubernetes.io/kube-apiserver-client   kubernetes-admin   24h                 Pending
[root@master231 ~]#

		2.3 服务端手动签发证书
[root@master231 ~]# kubectl certificate approve jiege-csr
certificatesigningrequest.certificates.k8s.io/jiege-csr approved
[root@master231 ~]#
[root@master231 ~]# kubectl get csr
NAME        AGE   SIGNERNAME                            REQUESTOR          REQUESTEDDURATION   CONDITION
jiege-csr   68s   kubernetes.io/kube-apiserver-client   kubernetes-admin   24h                 Approved,Issued
[root@master231 ~]#


		2.4 获取签发后的证书
[root@master231 ~]# kubectl get csr jiege-csr -o jsonpath='{.status.certificate}' | base64 -d > jiege.crt
[root@master231 ~]#
[root@master231 ~]# ll jiege.crt
-rw-r--r-- 1 root root 1115 Apr 14 10:57 jiege.crt
[root@master231 ~]#


		2.5 将证书拷贝到客户端节点，便于后续使用
[root@master231 ~]# scp jiege.crt 10.0.0.233:~

3.客户端测试验证

                 3.1 查看本地证书文件
[root@worker233 ~]# ll jiege.*
-rw-r--r-- 1 root root 1115 Apr 14 10:58 jiege.crt
-rw-r--r-- 1 root root  911 Apr 14 10:43 jiege.csr
-rw------- 1 root root 1704 Apr 14 10:43 jiege.key
[root@worker233 ~]#


		3.2 访问api-server
[root@worker233 ~]# kubectl -s https://10.0.0.231:6443 --client-key jiege.key  --client-certificate jiege.crt --insecure-skip-tls-verify get nodes
Error from server (Forbidden): nodes is forbidden: User "jiege" cannot list resource "nodes" in API group "" at the cluster scope
[root@worker233 ~]#

kubeconfig的组成部分

1.kubeconfig概述

kubeconfig是YAML格式的文件，用于存储身份认证信息，以便于客户端加载并认证到API Server。

kubeconfig保存有认证到一至多个Kubernetes集群的相关配置信息，并允许管理员按需在各配置间灵活切换
	clusters：
		Kubernetes集群访问端点（API Server）列表。
		说白了，就是可以定义多个K8S集群列表。
	users：
		认证到API Server的身份凭据列表。
		说白了，可以定义多个用户列表，这个用户可以是token，或者x509证书凭据。
	contexts：
		将每一个user同可认证到的cluster建立关联的上下文列表。
		说白了，就是将多个用户和对应的集群进行关联，将来使用哪个用户，就会去关联的集群进行访问认证。也可以定义多个上下文的关系。
	current-context:
		当前默认使用的context。

2.查看Kubeconfig证书文件内容

[root@master231 ~]# kubectl config view
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: DATA+OMITTED
    server: https://10.0.0.231:6443
  name: kubernetes
contexts:
- context:
    cluster: kubernetes
    user: kubernetes-admin
  name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
  user:
    client-certificate-data: REDACTED
    client-key-data: REDACTED
[root@master231 ~]#
[root@master231 ~]# kubectl config view --raw
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: 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
    server: https://10.0.0.231:6443
  name: kubernetes
contexts:
- context:
    cluster: kubernetes
    user: kubernetes-admin
  name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
  user:
    client-certificate-data: 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
    client-key-data: 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
[root@master231 ~]#

为静态令牌认证token用户生成kubeconfig实战

1 创建一个集群

[root@worker232 ~]# kubectl config set-cluster myk8s --embed-certs=true --certificate-authority=/etc/kubernetes/pki/ca.crt --server="https://10.0.0.231:6443" --kubeconfig=./lax-k8s.conf
Cluster "myk8s" set.
[root@worker232 ~]#
[root@worker232 ~]# cat ./lax-k8s.conf
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: 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
    server: https://10.0.0.231:6443
  name: myk8s
contexts: null
current-context: ""
kind: Config
preferences: {}
users: null
[root@worker232 ~]#
[root@worker232 ~]# ll lax-k8s.conf
-rw------- 1 root root 1663 Apr 14 11:26 lax-k8s.conf
[root@worker232 ~]#

2.查看集群信息

[root@worker232 ~]# kubectl config get-clusters --kubeconfig=./lax-k8s.conf
NAME
myk8s
[root@worker232 ~]#

3.查看令牌认证文件

[root@master231 ~]# cat /etc/kubernetes/pki/token.csv
01b202.d5c4210389cbff08,lax,10001,k8s
497804.9fc391f505052952,jasonyin,10002,k8s
8fd32c.0868709b9e5786a8,linux96,10003,k3s
jvt496.ls43vufojf45q73i,linux97,10004,k3s
qo7azt.y27gu4idn5cunudd,linux98,10005,k3s
mic1bd.mx3vohsg05bjk5rr,linux99,10006,k3s
[root@master231 ~]#

4.创建用户信息

[root@worker232 ~]# kubectl config set-credentials lax --token="01b202.d5c4210389cbff08" --kubeconfig=./lax-k8s.conf
User "lax" set.
[root@worker232 ~]#
[root@worker232 ~]# kubectl config set-credentials jasonyin --token="497804.9fc391f505052952" --kubeconfig=./lax-k8s.conf
User "jasonyin" set.
[root@worker232 ~]#
[root@worker232 ~]# cat lax-k8s.conf
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: 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
    server: https://10.0.0.231:6443
  name: myk8s
contexts: null
current-context: ""
kind: Config
preferences: {}
users:
- name: jasonyin
  user:
    token: 497804.9fc391f505052952
- name: lax
  user:
    token: 01b202.d5c4210389cbff08
[root@worker232 ~]#

5.查看用户信息

[root@worker232 ~]# kubectl config get-users --kubeconfig=./lax-k8s.conf
NAME
jasonyin
lax
[root@worker232 ~]#

6.定义上下文

[root@worker232 ~]# kubectl config set-context lax@myk8s --user=lax --cluster=myk8s --kubeconfig=./lax-k8s.conf
Context "lax@myk8s" created.
[root@worker232 ~]#
[root@worker232 ~]# kubectl config set-context jasonyin@myk8s --user=jasonyin --cluster=myk8s --kubeconfig=./lax-k8s.conf
Context "jasonyin@myk8s" created.
[root@worker232 ~]#
[root@worker232 ~]# cat lax-k8s.conf
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: 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
    server: https://10.0.0.231:6443
  name: myk8s
contexts:
- context:
    cluster: myk8s
    user: jasonyin
  name: jasonyin@myk8s
- context:
    cluster: myk8s
    user: lax
  name: lax@myk8s
current-context: ""
kind: Config
preferences: {}
users:
- name: jasonyin
  user:
    token: 497804.9fc391f505052952
- name: lax
  user:
    token: 01b202.d5c4210389cbff08
[root@worker232 ~]#

7.查看上下文列表

[root@worker232 ~]# kubectl config get-contexts --kubeconfig=./lax-k8s.conf
CURRENT   NAME                CLUSTER   AUTHINFO      NAMESPACE
          jasonyin@myk8s      myk8s     jasonyin
          lax@myk8s   myk8s     lax
[root@worker232 ~]#

8.定义当前使用的上下文

[root@worker232 ~]# kubectl config use-context lax@myk8s --kubeconfig=./lax-k8s.conf
Switched to context "lax@myk8s".
[root@worker232 ~]#
[root@worker232 ~]# cat lax-k8s.conf
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: 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
    server: https://10.0.0.231:6443
  name: myk8s
contexts:
- context:
    cluster: myk8s
    user: jasonyin
  name: jasonyin@myk8s
- context:
    cluster: myk8s
    user: lax
  name: lax@myk8s
current-context: lax@myk8s
kind: Config
preferences: {}
users:
- name: jasonyin
  user:
    token: 497804.9fc391f505052952
- name: lax
  user:
    token: 01b202.d5c4210389cbff08
[root@worker232 ~]#

9.查看当前使用的上下文

[root@worker232 ~]# kubectl config current-context --kubeconfig=./lax-k8s.conf
lax@myk8s
[root@worker232 ~]#
[root@worker232 ~]# kubectl config get-contexts --kubeconfig=./lax-k8s.conf
CURRENT   NAME                CLUSTER   AUTHINFO      NAMESPACE
          jasonyin@myk8s      myk8s     jasonyin
*         lax@myk8s   myk8s     lax
[root@worker232 ~]#

10.打印kubeconfig信息，默认会使用“REDACTED”或者“DATA+OMITTED”关键字隐藏证书信息

[root@worker232 ~]# kubectl config view --kubeconfig=./lax-k8s.conf
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: DATA+OMITTED
    server: https://10.0.0.231:6443
  name: myk8s
contexts:
- context:
    cluster: myk8s
    user: jasonyin
  name: jasonyin@myk8s
- context:
    cluster: myk8s
    user: lax
  name: lax@myk8s
current-context: lax@myk8s
kind: Config
preferences: {}
users:
- name: jasonyin
  user:
    token: REDACTED
- name: lax
  user:
    token: REDACTED
[root@worker232 ~]#
[root@worker232 ~]# kubectl config view --kubeconfig=./lax-k8s.conf --raw
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: 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
    server: https://10.0.0.231:6443
  name: myk8s
contexts:
- context:
    cluster: myk8s
    user: jasonyin
  name: jasonyin@myk8s
- context:
    cluster: myk8s
    user: lax
  name: lax@myk8s
current-context: lax@myk8s
kind: Config
preferences: {}
users:
- name: jasonyin
  user:
    token: 497804.9fc391f505052952
- name: lax
  user:
    token: 01b202.d5c4210389cbff08
[root@worker232 ~]#

11 客户端进行认证

[root@worker232 ~]# kubectl get pods --kubeconfig=./lax-k8s.conf
Error from server (Forbidden): pods is forbidden: User "lax" cannot list resource "pods" in API group "" in the namespace "default"
[root@worker232 ~]#
[root@worker232 ~]# kubectl get pods --kubeconfig=./lax-k8s.conf  --context=jasonyin@myk8s
Error from server (Forbidden): pods is forbidden: User "jasonyin" cannot list resource "pods" in API group "" in the namespace "default"
[root@worker232 ~]#

为X509数字证书的用户生成kubeconfig实战

1 准备证书

[root@worker233 ~]# ll jiege.*
-rw-r--r-- 1 root root 1115 Apr 14 10:58 jiege.crt
-rw-r--r-- 1 root root  911 Apr 14 10:43 jiege.csr
-rw------- 1 root root 1704 Apr 14 10:43 jiege.key
[root@worker233 ~]#

2 添加证书用户

[root@worker233 ~]#  kubectl config set-credentials jiege --client-certificate=/root/jiege.crt --client-key=/root/jiege.key --embed-certs=true --kubeconfig=./lax-k8s.conf
User "jiege" set.
[root@worker233 ~]#
[root@worker233 ~]# ll lax-k8s.conf
-rw------- 1 root root 3935 Apr 14 11:39 lax-k8s.conf
[root@worker233 ~]#
[root@worker233 ~]# cat lax-k8s.conf
apiVersion: v1
clusters: null
contexts: null
current-context: ""
kind: Config
preferences: {}
users:
- name: jiege
  user:
    client-certificate-data: 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
    client-key-data: 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
[root@worker233 ~]#

3 查看用户列表

[root@worker233 ~]#  kubectl config get-users --kubeconfig=./lax-k8s.conf
NAME
jiege
[root@worker233 ~]#

4.创建一个集群

[root@worker233 ~]# kubectl config set-cluster myk8s --embed-certs=false --certificate-authority=/etc/kubernetes/pki/ca.crt --server="https://10.0.0.231:6443" --kubeconfig=./lax-k8s.conf
Cluster "myk8s" set.
[root@worker233 ~]#
[root@worker233 ~]# ll /etc/kubernetes/pki/ca.crt
-rw-r--r-- 1 root root 1099 Apr 10 14:50 /etc/kubernetes/pki/ca.crt
[root@worker233 ~]#
[root@worker233 ~]# cat lax-k8s.conf
apiVersion: v1
clusters:
- cluster:
    certificate-authority: /etc/kubernetes/pki/ca.crt
    server: https://10.0.0.231:6443
  name: myk8s
contexts: null
current-context: ""
kind: Config
preferences: {}
users:
- name: jiege
  user:
    client-certificate-data: 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
    client-key-data: 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
[root@worker233 ~]#

5 配置上下文

[root@worker233 ~]# kubectl config set-context jiege@myk8s --user=jiege --cluster=myk8s --kubeconfig=./lax-k8s.conf
Context "jiege@myk8s" created.
[root@worker233 ~]#
[root@worker233 ~]# cat lax-k8s.conf
apiVersion: v1
clusters:
- cluster:
    certificate-authority: /etc/kubernetes/pki/ca.crt
    server: https://10.0.0.231:6443
  name: myk8s
contexts:
- context:
    cluster: myk8s
    user: jiege
  name: jiege@myk8s
current-context: ""
kind: Config
preferences: {}
users:
- name: jiege
  user:
    client-certificate-data: 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
    client-key-data: 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
[root@worker233 ~]#

6.查看上下文列表

[root@worker233 ~]# kubectl config get-contexts --kubeconfig=./lax-k8s.conf
CURRENT   NAME          CLUSTER   AUTHINFO   NAMESPACE
          jiege@myk8s   myk8s     jiege
[root@worker233 ~]#

7.查看kubeconfig信息

[root@worker233 ~]# kubectl --kubeconfig=./lax-k8s.conf config view
apiVersion: v1
clusters:
- cluster:
    certificate-authority: /etc/kubernetes/pki/ca.crt
    server: https://10.0.0.231:6443
  name: myk8s
contexts:
- context:
    cluster: myk8s
    user: jiege
  name: jiege@myk8s
current-context: ""
kind: Config
preferences: {}
users:
- name: jiege
  user:
    client-certificate-data: REDACTED
    client-key-data: REDACTED
[root@worker233 ~]#

8.客户端测试验证

[root@worker233 ~]# kubectl get pods --kubeconfig=./lax-k8s.conf
The connection to the server localhost:8080 was refused - did you specify the right host or port?
[root@worker233 ~]#
[root@worker233 ~]# kubectl get pods --kubeconfig=./lax-k8s.conf --context=jiege@myk8s
Error from server (Forbidden): pods is forbidden: User "jiege" cannot list resource "pods" in API group "" in the namespace "default"
[root@worker233 ~]#

9.配置默认上下文

[root@worker233 ~]# kubectl config use-context jiege@myk8s --kubeconfig=./lax-k8s.conf
Switched to context "jiege@myk8s".
[root@worker233 ~]#
[root@worker233 ~]# cat lax-k8s.conf
apiVersion: v1
clusters:
- cluster:
    certificate-authority: /etc/kubernetes/pki/ca.crt
    server: https://10.0.0.231:6443
  name: myk8s
contexts:
- context:
    cluster: myk8s
    user: jiege
  name: jiege@myk8s
current-context: jiege@myk8s
kind: Config
preferences: {}
users:
- name: jiege
  user:
    client-certificate-data: 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
    client-key-data: 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
[root@worker233 ~]#

10.再次测试

[root@worker233 ~]# kubectl config current-context --kubeconfig=./lax-k8s.conf
jiege@myk8s
[root@worker233 ~]#
[root@worker233 ~]# kubectl config get-contexts --kubeconfig=./lax-k8s.conf
CURRENT   NAME          CLUSTER   AUTHINFO   NAMESPACE
*         jiege@myk8s   myk8s     jiege
[root@worker233 ~]#
[root@worker233 ~]# kubectl get pods --kubeconfig=./lax-k8s.conf
Error from server (Forbidden): pods is forbidden: User "jiege" cannot list resource "pods" in API group "" in the namespace "default"
[root@worker233 ~]#

发表回复取消回复

Related News

Jenkins集成K8S集群

玩转Pod调度

kubeadm实现K8S集群的扩容和缩容，周期性备份etcd数据以及图形化管理K8S集群kuboard的搭建

You may have missed

kafka单点部署-和kafka集群搭建

zookeeper单点部署以及集群搭建

Kibana如何部署

Prometheus监控es集群

归档

其他

API Server内置的访问控制机制

静态令牌文件认证测试案例

X509数字证书认证测试案例

kubeconfig的组成部分

为静态令牌认证token用户生成kubeconfig实战

为X509数字证书的用户生成kubeconfig实战

发表回复 取消回复

Related News

Jenkins集成K8S集群

玩转Pod调度

kubeadm实现K8S集群的扩容和缩容，周期性备份etcd数据以及图形化管理K8S集群kuboard的搭建

You may have missed

kafka单点部署-和kafka集群搭建

zookeeper单点部署以及集群搭建

Kibana如何部署

Prometheus监控es集群

发表回复取消回复
