标签管理进阶

	1.标签的分类
标签用于对数据分组和分类，利用标签可以将数据进行过滤筛选。

标签管理的常见场景:
	- 1.删除不必要的指标;
	- 2.从指标中删除敏感或不需要的标签;
	- 3.添加，编辑或修改指标的标签值或标签格式;

标签的分类:
	- 默认标签:
		Prometheus自身内置的标签，格式为"__LABLE__"。
		如上图所示，典型点如下所示:
        	- "__metrics_path__"
        	- "__address__"
        	- "__scheme__"
        	- "__scrape_interval__"
        	- "__scrape_timeout__"
			- "__name__"
        	- "instance"
        	- "job"

	- 应用标签:
		应用本身内置，尤其是监控特定的服务，会有对应的应用标签，格式一般为"__LABLE"
		如下图所示，以consul服务为例，典型点如下所示:
			- "__meta_consul_address"
			- "__meta_consul_service"
			- "__meta_consul_dc"
			- ...

	- 自定义标签:
		指的是用户自定义的标签，我们在定义targets可以自定义。

relabel_configs修改target标签案例

1.为targets自定义打标签案例
		1.1 修改配置文件
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# vim prometheus.yml
...
  - job_name: "violet-linux-node-exporter-labels"
    static_configs:
      - targets: ["10.0.0.41:9100","10.0.0.42:9100","10.0.0.43:9100"]
        labels:
          auther: violet
          office: https://www.violet.com
...
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# ./promtool check config prometheus.yml
Checking prometheus.yml
 SUCCESS: prometheus.yml is valid prometheus config file syntax

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#

1.2.热加载配置
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# curl -X POST http://10.0.0.31:9090/-/reload
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#


		1.3.查询数据验证
node_cpu_seconds_total{office="https://www.violet.com"}

2.relabel_configs使用target_label新增标签

2.1 修改配置文件
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# vim prometheus.yml
...
  - job_name: "violet-linux-node-exporter-relabel_configs-target_label"
    static_configs:
      - targets: ["10.0.0.31:9100","10.0.0.41:9100","10.0.0.42:9100","10.0.0.43:9100"]
    relabel_configs:
      # 匹配源标签的值
    - source_labels:
      - job
      # 将匹配到的值赋值给新标签
      target_label: linux96_jobs
...
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# ./promtool check config prometheus.yml
Checking prometheus.yml
 SUCCESS: prometheus.yml is valid prometheus config file syntax

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# curl -X POST http://10.0.0.31:9090/-/reload
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#

		2.2 测试验证
node_cpu_seconds_total{linux96_jobs="oldboyedu-linux96-node-exporter-relabel_configs-target_label"}

3.relabel_configs替换标签replace案例

3.1 修改配置文件
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# vim prometheus.yml
...
  - job_name: "violet-linux-node-exporter-relabel_configs-regex-separator-replacement-action"
    static_configs:
      - targets: ["10.0.0.31:9100","10.0.0.41:9100","10.0.0.42:9100","10.0.0.43:9100"]
    relabel_configs:
      # 指定正则表达式匹配成功的label进行标签管理的列表
    - source_labels:
      - __scheme__
      - __address__
      - __metrics_path__
      # 表示source_labels对应Label的名称或值进行匹配此处指定的正则表达式。
      # 此处我们对数据进行了分组，后面replacement会是哟合格"${1}"和"$2"进行引用。
      regex: "(http|https)(.*)"
      # 指定用于连接多个source_labels为一个字符串的分隔符，若不指定，默认为分号";"。
      # 假设源数据如下:
      # 	__address__="10.0.0.41:9100"
      #		__metrics_path__="/metrics"
      #		__scheme__="http"
      # 拼接后操作的结果为: "http10.0.0.41:9100/metrics"
      separator: ""
      # 在进行Label替换的时候，可以将原来的source_labels替换为指定修改后的label。
      # 将来会新加一个标签，标签的名称为"yinzhengjie_prometheus_ep"，值为replacement的数据。
      target_label: "yinzhengjie_prometheus_ep"
      # 替换标签时，将target_label对应的值进行修改成此处的值，如果不指定，默认使用"$1"
      replacement: "${1}://${2}"
      # 对Label或指标进行管理，场景的动作有replace|keep|drop|lablemap|labeldrop等，默认为replace。
      # 参考链接地址:
      #    https://prometheus.io/docs/prometheus/2.53/configuration/configuration/#relabel_config
      action: replace

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# ./promtool check config prometheus.yml
Checking prometheus.yml
 SUCCESS: prometheus.yml is valid prometheus config file syntax

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# curl -X POST http://10.0.0.31:9090/-/reload
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#

		3.2 测试验证
node_cpu_seconds_total{job="violet-linux-node-exporter-relabel_configs-regex-separator-replacement-action"}

4.relabel_configs新增标签映射labelmap案例

4.1 修改配置文件
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# vim prometheus.yml
  - job_name: "violet-linux-node-exporter-relabel_configs-labelmap"
    static_configs:
      - targets: ["10.0.0.31:9100","10.0.0.41:9100","10.0.0.42:9100","10.0.0.43:9100"]
    relabel_configs:
    - regex: "(job|app)"
      replacement: "${1}_yinzhengjie_labelmap_kubernetes"
      # labelmap一般用于生成新的标签，通常用于取出匹配标签名的一部分生成新标签，旧的标签依旧会存在。
      # 将regex对source label中指定的标签名称进行匹配，而后将匹配到的标签的赋值给replacement字段指定的标签。
      action: labelmap
...
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# ./promtool check config prometheus.yml
Checking prometheus.yml
 SUCCESS: prometheus.yml is valid prometheus config file syntax

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# curl -X POST http://10.0.0.31:9090/-/reload
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#

		4.2 测试验证
node_cpu_seconds_total{job="violet-linux-node-exporter-relabel_configs-labelmap"}

5.relabel_configs删除标签labeldrop案例

5.1 修改配置文件
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# vim prometheus.yml
...
  - job_name: "violet-linux-node-exporter-relabel_configs-labelmap-labeldrop"
    static_configs:
      - targets: ["10.0.0.31:9100","10.0.0.41:9100","10.0.0.42:9100","10.0.0.43:9100"]
    relabel_configs:
    - regex: "(job|app)"
      replacement: "${1}_yinzhengjie_labelmap_kubernetes"
      action: labelmap
    - regex: "(job|app)"
      # 删除regex匹配到的标签
      action: labeldrop
...
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# curl -X POST http://10.0.0.31:9090/-/reload
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# ./promtool check config prometheus.yml
Checking prometheus.yml
 SUCCESS: prometheus.yml is valid prometheus config file syntax

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# curl -X POST http://10.0.0.31:9090/-/reload
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#


		5.2 验证测试
node_cpu_seconds_total{job_violet_labelmap_kubernetes="violet-linux-node-exporter-relabel_configs-labelmap-labeldrop"}

6.metric_relabel_configs修改metric标签案例

6.1 测试案例
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# vim prometheus.yml
...
  - job_name: "violet-linux-node-exporter-metric_relabel_configs-drop"
    static_configs:
      - targets: ["10.0.0.31:9100","10.0.0.41:9100","10.0.0.42:9100","10.0.0.43:9100"]
    metric_relabel_configs:
    - source_labels:
      - __name__
      regex: "node_cpu_.*"
      action: drop
      #target_label: "xixi"
      #action: uppercase
    - regex: "(id|pretty_name|version_codename)"
      action: labeldrop

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# systemctl stop prometheus-server.service
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# ./promtool check config prometheus.yml
Checking prometheus.yml
 SUCCESS: prometheus.yml is valid prometheus config file syntax

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# rm -rf data/
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# ./prometheus

		6.2 测试验证
node_cpu_seconds_total{job="violet-linux-node-exporter-metric_relabel_configs-drop"}
node_os_info{name="Ubuntu"}

pushgateway组件部署

1.什么是pushgateway

说白了，就是自定义监控。

2.部署pushgateway

wget https://github.com/prometheus/pushgateway/releases/download/v1.11.0/pushgateway-1.11.0.linux-amd64.tar.gz

3.解压软件包

[root@node-exporter41 ~]# tar xf pushgateway-1.11.0.linux-amd64.tar.gz -C /usr/local/bin/ pushgateway-1.11.0.linux-amd64/pushgateway --strip-components=1
[root@node-exporter41 ~]#
[root@node-exporter41 ~]# ll /usr/local/bin/pushgateway
-rwxr-xr-x 1 1001 1002 20656129 Jan  9 22:36 /usr/local/bin/pushgateway*
[root@node-exporter41 ~]#

4.运行pushgateway

[root@node-exporter41 ~]# pushgateway --web.telemetry-path="/metrics" --web.listen-address=:9091 --persistence.file=/oldboyedu/data/pushgateway.data

5.访问pushgateway的WebUI

http://10.0.0.41:9091/#

模拟直播在线人数统计

1 使用curl工具推送测试数据pushgateway

[root@elk93 dockerfile]# echo "student_online 35" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.93


[root@elk93 dockerfile]# echo "student_online $RANDOM" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.93
[root@elk93 dockerfile]#

2 查看pushgateway的WebUI

[root@elk93 dockerfile]# curl -s http://10.0.0.41:9091/metrics | grep ^student_online
student_online{instance="10.0.0.93",job="violet_student"} 35
[root@elk93 dockerfile]#

3.修改prometheus的配置文件

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# vim prometheus.yml
  ...
  - job_name: "prometheus-violet-pushgatway"
    # 如果pushgateway组件的标签和prometheus server冲突时，如何解决的问题。
    # 会直接覆盖哟，默认为false(会将源标签加上"exported_"前缀)表示不覆盖，此处我显示定义为true。
    # honor_labels: true
    static_configs:
    - targets:
        - "10.0.0.41:9091"

4.重新加载配置

curl -X POST http://10.0.0.31:9090/-/reload

5.验证配置是否生效

http://10.0.0.31:9090/config
http://10.0.0.31:9090/targets?search=

搜索指标:	"student_online"

6.grafana出图展示

echo "student_online 35" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.71
echo "student_online 45" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.72
echo "student_online 55" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.73
echo "student_online 65" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.74
echo "student_online 75" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.75
echo "student_online 135" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.71
echo "student_online 5" | curl --data-binary @-  http://10.0.0.41:9091/metrics/job/violet_student/instance/10.0.0.71

周期性上报直播在线人数

[root@elk93 ~]# chmod +x /tmp/zhibo.sh
[root@elk93 ~]#
[root@elk93 ~]# cat /tmp/zhibo.sh
#!/bin/bash
# Filename: zhibo.sh

/usr/bin/echo "student_online $RANDOM" | /usr/bin/curl --data-binary @-  http://10.0.0.41:9091/metrics/job/oldboyedu_student/instance/10.0.0.93
[root@elk93 ~]#
[root@elk93 ~]# echo '* * * * * /tmp/zhibo.sh' > /var/spool/cron/crontabs/root
[root@elk93 ~]#
[root@elk93 ~]# crontab -l
* * * * * /tmp/zhibo.sh
[root@elk93 ~]#


存在问题：
	貌似这样无法定时上报任务到pushgateway，需要进一步研究。

Prometheus监控TCP的12种状态

1.监控TCP的12种状态

[root@elk93 ~]# cat /usr/local/bin/tcp_status2.sh
#!/bin/bash

pushgateway_url="http://10.0.0.41:9091/metrics/job/tcp_status"
time=$(date +%Y-%m-%d+%H:%M:%S)

state="SYN-SENT SYN-RECV FIN-WAIT-1 FIN-WAIT-2 TIME-WAIT CLOSE CLOSE-WAIT LAST-ACK LISTEN CLOSING ESTAB"
for i in  $state
 do
 t=`ss -tan |grep $i |wc -l`
 echo tcp_connections{state=\""$i"\"} $t >>/tmp/tcp.txt
done;

cat /tmp/tcp.txt | curl --data-binary @- $pushgateway_url
rm -rf  /tmp/tcp.txt
[root@elk93 ~]#

2.调用脚本

[root@elk93 ~]# bash /usr/local/bin/tcp_status2.sh

SRE运维开发实现自定义的exporter

1.使用python程序自定义exporter案例


		1.1 安装pip3工具包
[root@prometheus-node42 ~]#  apt update
[root@prometheus-node42 ~]#  apt install -y python3-pip


		1.2 安装实际环境中相关模块库
[root@elk93 ~]# pip3 install flask prometheus_client -i https://mirrors.aliyun.com/pypi/simple


		1.3 编写代码
[root@elk93 ~]# cat flask_metric.py
#!/usr/bin/python3
# auther: violet
# blog: https://www.vionletarchitect.top

from prometheus_client import start_http_server,Counter, Summary
from flask import Flask, jsonify
from wsgiref.simple_server import make_server
import time

app = Flask(__name__)

# Create a metric to track time spent and requests made
REQUEST_TIME = Summary('request_processing_seconds', 'Time spent processing request')
COUNTER_TIME  = Counter("request_count", "Total request count of the host")

@app.route("/apps")
@REQUEST_TIME.time()
def requests_count():
    COUNTER_TIME.inc()
    return jsonify({"office": "https://www.vionletarchitect.top"},{"auther":"violet"})

if __name__ == "__main__":
    print("启动程序: violet-linux-python-exporter, 访问路径: http://0.0.0.0:8001/apps，监控服务: http://0.0.0.0:8000")
    start_http_server(8000)
    httpd = make_server( '0.0.0.0', 8001, app )
    httpd.serve_forever()
[root@elk93 ~]#


		1.4 启动python程序
[root@elk93 ~]# python3 flask_metric.py
启动老男孩教育程序: oldboyedu-linux96-python-exporter, 访问路径: http://0.0.0.0:8001/apps，监控服务: http://0.0.0.0:8000
10.0.0.1 - - [30/Mar/2025 15:03:14] "GET /apps HTTP/1.1" 200 64
10.0.0.1 - - [30/Mar/2025 15:03:26] "GET /apps HTTP/1.1" 200 64


		1.5 客户端测试
[root@node-exporter43 ~]# cat violet_curl_metrics.sh
#!/bin/bash

URL=http://10.0.0.93:8001/apps

while true;do
    curl_num=$(( $RANDOM%50+1 ))
    sleep_num=$(( $RANDOM%5+1 ))
    for c_num in `seq $curl_num`;do
        curl -s $URL &> /dev/null
    done
    sleep $sleep_num
done
[root@node-exporter43 ~]#
[root@node-exporter43 ~]# bash -x violet_curl_metrics.sh

2.prometheus监控python自定义的exporter实战

2.1 编辑配置文件
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# vim prometheus.yml
...

  - job_name: "violet_python_custom_metrics"
    static_configs:
      - targets:
        - 10.0.0.93:8000
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#

		2.2 检查配置文件语法
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#  ./promtool check config  prometheus.yml
Checking prometheus.yml
 SUCCESS: prometheus.yml is valid prometheus config file syntax

[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#


		2.3 重新加载配置文件
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]# curl -X POST http://10.0.0.31:9090/-/reload
[root@prometheus-server31 prometheus-2.53.4.linux-amd64]#



		2.4 验证prometheus是否采集到数据
http://10.0.0.31:9090/targets


		2.5 grafana作图展示
request_count_total
	老男孩教育apps请求总数。


increase(request_count_total{job="violet_python_custom_metrics"}[1m])
	老男孩教育每分钟请求数量曲线QPS。


irate(request_count_total{job="violet_python_custom_metrics"}[1m])
	老男孩教育每分钟请求量变化率曲线

request_processing_seconds_sum{job="violet_python_custom_metrics"} / request_processing_seconds_count{job="violet_python_custom_metrics"}
	老男孩教育每分钟请求处理平均耗时

发表回复取消回复

Related News

Prometheus监控es集群

Prometheus的快速安装和使用

Prometheus的Altermanager组件实现告警，配置自定义告警模板，以及结合钉钉插件如何实现告警

You may have missed

kafka单点部署-和kafka集群搭建

zookeeper单点部署以及集群搭建

Kibana如何部署

Prometheus监控es集群

归档

其他

pushgateway组件部署

模拟直播在线人数统计

周期性上报直播在线人数

Prometheus监控TCP的12种状态

SRE运维开发实现自定义的exporter

发表回复 取消回复

Related News

Prometheus监控es集群

Prometheus的快速安装和使用

Prometheus的Altermanager组件实现告警，配置自定义告警模板，以及结合钉钉插件如何实现告警

You may have missed

kafka单点部署-和kafka集群搭建

zookeeper单点部署以及集群搭建

Kibana如何部署

Prometheus监控es集群

发表回复取消回复
